Marine Cast Steel 10K Globe Valve JIS F7319

Category: JIS Marine Valve

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote

Dowdload Page

We can supply according to your requirement.

Marine Cast Steel 10K Globe Valve JIS F7319

China Marine Cast Steel 10K Globe Valve JIS F7319:

Marine Cast Steel 10K Globe Valve JIS F7319 is used to shut off/turn on the medium and adjust the flow rate in the marine steam, fresh water, water feeding, fuel oil and lubrication oil pipe lines.

Technical Specification:

1. Design and manufacturing standard: JIS F7319-1996

2. Inspection and Test standard: JIS F7400

3. Hydraulic Pressure Test: Body---2.1Mpa, Seat---1.54Mpa

4. Connection Type: Flange

5. Flange Standard: JIS B2220 10K

6. Warranty: 12months

Max Working Pressure:

Fluid Condition	Max Working Pressure (Mpa)
Steam of 300℃	1.0
Steam of 200℃ or less	1.2
Air, oil, gas and pulsation water	1.2
non-shock water of 120℃ or less	1.4

Main Material:

1-Body:Cast Steel

2-Seat: Stainless Steel

3-Disc:Stainless Steel

4-Stem: Stainless Steel

5-Bonnet: Cast Steel

6-Handwheel: Cast Iron

Main Size(mm):

IMPA CODE	Size	L	D	C	t	No of bolt hole	h	H	D2	Weight(kgs)
750411	50	220	155	120	16	4	19	270	160	17.9
750412	65	270	175	140	18	4	19	300	200	26
750413	80	300	185	150	18	8	19	310	200	29.8
750414	100	350	210	175	18	8	19	355	250	44.7
750415	125	420	250	210	20	8	23	415	280	70.3
750416	150	490	280	240	22	8	23	470	315	96.4
750417	200	570	330	290	22	12	23	565	355	159
750418	250	740	400	355	24	12	25	645	400	257
750419	300	840	445	400	24	16	25	735	450	370
