Marine Bronze/Brass Globe Valve JIS F7303 16K

Marine Bronze/Brass Globe Valve JIS F7303 16K

China Marine Bronze/Brass Globe Valve JIS F7303 16K:

Marine Globe Valve is the stop valve used on the marine pipe system to open or close the pipe system and control the flow rate. Marine Bronze/Brass Globe Valve can be used for sea water, fresh water, fuel oil, lubrication oil & Steam pipe system.

If the size is DN10~DN40, the bonnet is screwed type, if the size is DN50 and bove DN50, the bonnet is bolted type.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7303

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220

5.Hydraulic Pressure Test: Body-3.3Mpa, Seat-2.42Mpa

6. Max Working Pressure: 1.6Mpa for air, gas, oil, pulsation water and steam of 205℃ or less, 2.2Mpa for non-shock water of 120℃ or less

7. Warranty: 12months

8. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Bonnet:Bronze / Brass

5-Handwheel: Cast Iron (HT200)

Main Data of Joining(mm):
