Micro Electric Hoist:
Micro Electric Hoist Introduction
220V hoist is convenient for house.
The hoist design smart, portable usage.
When the goods across the limited device, the motor will stop.
Rope reverse raise, hoist motor will stop working immediately.
Hook design is divided into two stages: static loading and dynamic loading.
Hook can swivel 360 degrees, prevent wire rope swiveling.
Protection rank is IP54, with heat protection device.
Product Details
The sizes table
| Model | Method | Rated Voltage(V) | Input Power(W) | Rated Capacity(KG) | Lifting Speed(m) | lifting Height(m） | Qty/CTN (pcs) | Package Size(cm) | GW/NW(KG) |
| PA200B | Single-Hook | 220/230V 50/60HZ | 480 | 100 | 10 | 12 | 2 | 38x32x25 | 22.5/22 |
| Double-Hook | 200 | 5 | 6 | ||||||
| PA250B | Single-Hook | 510 | 125 | 10 | 12 | 23/22 | |||
| Double-Hook | 250 | 5 | 6 | ||||||
| PA300B | Single-Hook | 600 | 150 | 10 | 12 | 23.5/23 | |||
| Double-Hook | 300 | 5 | 6 | ||||||
| PA400B | Single-Hook | 950 | 200 | 10 | 12 | 45x34x27 | 33/22 | ||
| Double-Hook | 400 | 5 | 6 | ||||||
| PA500B | Single-Hook | 1020 | 250 | 10 | 12 | 33.5/22.5 | |||
| Double-Hook | 500 | 5 | 6 | ||||||
| PA600B | Single-Hook | 1200 | 300 | 10 | 12 | 35/34 | |||
| Double-Hook | 600 | 5 | 6 | ||||||
| PA800B | Single-Hook | 1300 | 400 | 8 | 12 | 38/38 | |||
| Double-Hook | 800 | 4 | 6 | ||||||
| PA1000B | Single-Hook | 1600 | 500 | 8 | 12 | 1 | 54x25x32 | 32/31 | |
| Double-Hook | 1000 | 4 | 6 |
