Marine Inflatable Rubber Fender
Marine Inflatable Rubber Fender
Description:
All kinds of sizes and types available.
Intial pressure:0.05MPa and 0.08MPa can be supplied, as per your need.
Conform toISO 17357-2002 directives.
Certificate :BV,ABS,CCS etc.
It can help the ship mooring easiely and safe,reduce the hurt to both ship and jetty.
Size Chart:
| No. | Size | Initial pressure | Energy absorption | Reaction force |
| (Diameter x Length) | ||||
| mm x mm | MPa | KJ | KN | |
| 1 | 500 x 1000 | 0.05 | 6 | 64 |
| 2 | 600 x 1000 | 0.05 | 8 | 74 |
| 3 | 700 x 1500 | 0.05 | 17 | 137 |
| 4 | 1000 x 1500 | 0.05 | 32 | 182 |
| 5 | 1000 x 2000 | 0.05 | 45 | 257 |
| 6 | 1200 x 2000 | 0.05 | 63 | 297 |
| 7 | 1350 x 2500 | 0.05 | 102 | 427 |
| 8 | 1500 x 3000 | 0.05 | 153 | 579 |
| 9 | 1700 x 3000 | 0.05 | 191 | 639 |
| 10 | 2000 x 3500 | 0.05 | 308 | 875 |
| 11 | 2500 x 4000 | 0.05 | 663 | 1381 |
| 12 | 2500 x 5000 | 0.05 | 857 | 1835 |
| 13 | 2500 x 5500 | 0.05 | 943 | 2019 |
| 14 | 3000 x 5000 | 0.05 | 1050 | 2000 |
| 15 | 3000 x 6000 | 0.05 | 1312 | 2488 |
| 16 | 3300 x 4500 | 0.05 | 1175 | 1884 |
| 17 | 4500 x 9000 | 0.05 | 4752 | 5747 |
| 18 | 4500 x 12000 | 0.05 | 6473 | 7984 |
