D Type Fender
China D Type Fender:
Description:
Nature rubber material D type fender,the D type fender can be with taper or without taper,depend on your need,without taper D type fender is more beautiful.
Size 250x250 is the popular size.
About the installation holes and accessories, we can equip with it if you need.
Size Chart:
| Specification | H(mm) | B(mm) | L(mm) | Holes |
| D100*100*2000 | 100 | 100 | 2000 | 5 |
| D150*150*2000 | 150 | 150 | 2000 | 5 |
| D160*150*2500 | 160 | 150 | 2500 | 6 |
| D200*200*850 | 200 | 200 | 850 | 3 |
| D200*200*900 | 200 | 200 | 900 | 2 |
| D200*200*1000 | 200 | 200 | 1000 | 3 |
| D200*200*1500 | 200 | 200 | 1500 | 3 |
| D250*250*1000 | 250 | 250 | 1000 | 3 |
| D250*250*1500 | 250 | 250 | 1500 | 3 |
| D300*300*850 | 300 | 300 | 850 | 3 |
| D300*360*850 | 300 | 360 | 850 | 3 |
| D300*300*900 | 300 | 300 | 900 | 2 |
| D300*300*1000 | 300 | 300 | 1000 | 3 |
| D300*300*1500 | 300 | 300 | 1500 | 4 |
| D300*360*1000 | 300 | 360 | 1000 | 3 |
| D300*360*1500 | 300 | 360 | 1500 | 4 |
| D400*400*850 | 400 | 400 | 850 | 3 |
| D400*400*1000 | 400 | 400 | 1000 | 3 |
| D400*400*1500 | 400 | 400 | 1500 | 3 |
| D500*500*850 | 500 | 500 | 850 | 3 |
| D500*500*1000 | 500 | 500 | 1000 | 3 |
| D500*500*1500 | 500 | 500 | 1500 |
3 |
