Super Arch Rubber Fender:
China Super Arch Rubber Fender:
Description:
Adopt nature rubber material,inside the fender is steel plate,the structure and installation is very simple, but with high stability and reliable quality,no need to do maintanance frequently.
It can be fitted vertically or horizontally. The energy absorption of super arch rubber fenders is 2.3 times better than D type rubber fender, 3.5 times higher than the cylindrical rubber fenders.
Some client prefer to install UHMW-PE face pads on the surface of super arch rubber fenders .
Available sizes from 200mm to 1000mmhigh and in lengths of 1000mm to 3500mm. .
Size Chart:
| Types | Specification(mm) | ||||
| H | L | L1 | B | B2 | |
| SA-001 | 150 | 1000 | 1075 | 98 | 300 |
| SA-002 | 150 | 2000 | 2075 | 98 | 300 |
| SA-003 | 150 | 3000 | 3075 | 98 | 300 |
| SA-004 | 200 | 1000 | 1100 | 135 | 400 |
| SA-005 | 200 | 2000 | 2100 | 135 | 400 |
| SA-006 | 200 | 3000 | 3100 | 135 | 400 |
| SA-007 | 250 | 1000 | 1125 | 164 | 500 |
| SA-008 | 250 | 2000 | 2125 | 164 | 500 |
| SA-009 | 250 | 3000 | 3125 | 164 | 500 |
| SA-010 | 300 | 1000 | 1150 | 225 | 600 |
| SA-011 | 300 | 2000 | 2150 | 225 | 600 |
| SA-012 | 300 | 3000 | 3150 | 225 | 600 |
| SA-013 | 400 | 1000 | 1200 | 300 | 800 |
| SA-014 | 400 | 2000 | 2200 | 300 | 800 |
| SA-015 | 400 | 3000 | 3200 | 300 | 800 |
| SA-016 | 500 | 1000 | 1250 | 375 | 1000 |
| SA-017 | 500 | 2000 | 2250 | 375 | 1000 |
| SA-018 | 500 | 3000 | 3250 | 375 | 1000 |
| SA-019 | 600 | 1000 | 1300 | 450 | 1200 |
| SA-020 | 600 | 2000 | 2300 | 450 | 1200 |
| SA-021 | 600 | 3000 | 3300 | 450 | 1200 |
| SA-022 | 800 | 1000 | 1400 | 600 | 1600 |
| SA-023 | 800 | 2000 | 2400 | 600 | 1600 |
| SA-024 | 800 | 3000 | 3400 | 600 | 1600 |
| SA-025 | 1000 | 1500 | 2000 | 750 | 2000 |
