VT Chain Block Hoist
China VT Chain Block Hoist:
VT Chain Block Hoist
The VT Series Hand Chain Hoist is a lightweight yetrobust lifting solution engineered for highintensity operations, ideal for workshop assembly, equipment main-tenance, and warehouse logistics. Featuring a high-strength alloy steel frame and wear-resistant loadchains, combined with an optimized gear transmission system, it safely handles loads from 0.5 to 20 tons, balancing portability and durability.
| Model | Lifting Capacity（T) | Lifting Height(M) | Testing Load(T) | Minimum Distance Between Two Hooks(N) | Number of Chains | Chain Diameter(mm) | Dimensions | Weight(KG) | |||||||
| A | B | C | Φ | H | |||||||||||
| 1T | 1 | 3 | 1.5 | 250 | 1 | 6 | 151 | 172 | 32 | 37 | 376 | 12 | |||
| 2T | 2 | 3 | 3 | 335 | 1 | 8 | 175 | 210 | 36 | 45 | 470 | 19 | |||
| 3T | 3 | 3 | 4.5 | 370 | 2 | 10 | 176 | 230 | 46 | 55 | 565 | 26 | |||
| 5T | 5 | 3 | 7.5 | 360 | 2 | 10 | 189 | 280 | 46 | 65 | 688 | 42 | |||
| 10T | 10 | 3 | 12.5 | 380 | 4 | 10 | 189 | 463 | 57 | 85 | 765 | 70 | |||
