MRE-M2XCH LSOH (SHF1) Sheathed Armoured Fire Resistant Instrumentation & Control Cables:

Basic Parameters

Cable Feature: 150/250V Mica Tape + XLPE Insulated, LSOH (SHF1) Sheathed, Armoured Fire Resistant.

Bending Radius: 6×OD

Temperature Range: -30℃ ~ +80℃

Standards

IEC 60092-350/351/376/359, IEC 60331-21, IEC 60332-1, IEC 60332-3-22, IEC 60754-1/2, IEC 61034.

Construction

Conductors: Class 2 stranded copper conductor.

Insulation: Mica tape + XLPE.

Cabling Element: Pair/Triple.

Inner Covering: Lapped polyester tape.

Armour: Copper wire braid.

Outer Sheath: LSOH (SHF1). SHF2 can be offered upon request。
