MTX 3.6/6kV 6/10kV 8.7/15kV XLPE Insulated MV Power Cables (SHF1 Inner Sheath)

Category: IEC60092 Standard Offshore & Marine Cables
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
FOB Price: Get Latest Price Now
Warranty: 12 Months unless specified otherwise
Place of Origin: China
Request a Quote Print Page Print Page

We can supply according to your requirement.

MTX 3.6/6kV 6/10kV 8.7/15kV XLPE Insulated MV Power Cables (SHF1 Inner Sheath)

Basic Parameters

Cable Feature:Flame retardant, low smoke & halogen free.

Bending Radius: 12×OD (single core); 9×OD (three core)
Temperature Range: -30℃ ~ +80℃

Cable Standards
IEC 60092-350/351/354/359
Construction
Conductors: Class 2 stranded copper conductor.
Conductor Screen: Semi-conducting layer (tape/compound).
Insulation: XLPE.
Insulation Screen: Semi-conducting layer (tape/compound).
Metallic Screen: Copper tape
Inner Sheath: LSOH (SHF1).
Armour: Copper wire braid or galvanized steel wire braid.
Outer Sheath: LSOH (SHF1). SHF2 can be offered upon request
