HC-65A Marine Air Compressor
1.Main Function
HC-65A air compressor is mainly used in large and medium-sized ship and stationary diesel engine starting, also can be used as other industrial departments and the origin of compressed air pressure test.
2. Institutional characteristics
HC-65A air compressor is vertical, water cooling, the secondary compression.
Cooling, pressure equalization, pump pressure can be adjusted.
Equipped with automatic control system according to the requirement of the customers.
Automatic control functions: automatic start, automatic stop, automatic unloading, low voltage alarm, oil discharge ultra-high alarm, low pressure alarm.
Main Technical Parameter
| Model | Type | Displacement capacity | Specified Pressure | Rotating Speed | Motor Power | Weight | Overrall Size (L*W*H) |
| m3/h | Mpa | r/min | KW | Kg | mm | ||
| HC-65A | Vertical type water cooled two stage compression piston type | 69 | 3.0 | 750 | 18.5 | 700 | 1430*900*1260 |
| 82 # | 900 | 22 | |||||
| 90 | 960 | 22 | |||||
| HC-265A | 137 | 750 | 37 | 1400 | 1870*1000*1180 | ||
| 170# | 900 | 45 | |||||
| 190 | 960 | 45 | |||||
| Remarks: # On behalf of 440V Suitable for 1.0 -3.0 cube air bottle | |||||||
