CZ-20/30 Marine air compressor
Models: CZ-20/30 Marine air compressor
Type: single, water-cooled, secondary differential piston, belt drive
Displacement: 20 m3 / h
The rated pressure: 3.0 Mpa
Product features
1.It has simple structure, highly efficient, light weight, small volume, low noise, low exhaust temperature, smooth operation.
2.Apply to ship host and various medium-sized diesel engine start, can also be used for hydro power station of brake, all kinds of valves, instrumentation, container pressure testing for pressure air supply and other fields.
3.According to the needs of users of products can provide the following functions: two main for the functions of each control, temperature control, inlet pressure controller, exhaust outlet high pressure hose.
Main Technical Parameter
| Model | Displacement | Specified | Rotating | Motor Power | Dimension （L×W×H） | Weight | ||
| Pressure | Speed | |||||||
| m3/h | m3/ min | MPa | r/min | kW | HP | mm | kg | |
| CZ-20/30SZK | 20 | 0.34 | 3.0 | 960 | 5.5 | 7.5 | 900×600×850 | 250 |
| CZ-20/30SZK | 1000 | 1070×490×810 | 225 | |||||
| CV-30/30 | 30 | 0.5 | 720 | 7.5 | 10 | 1230×730×690 | 330 | |
| CV-40/30 | 40 | 0.67 | 870 | 11 | 15 | 1230×730×690 | 340 | |
| CV-50/30 | 50 | 0.83 | 970 | 11 | 15 | 1230×730×690 | 340 | |
| CV-90/30 | 90 | 1.5 | 730 | 22 | 30 | 1600×1010×1050 | 900 | |
| CV-120/30 | 120 | 2 | 975 | 30 | 40 | 1600×1010×1050 | 1000 | |
