HC-265A Marine Air Compressor
Main Technical Parameter
| Model | Type | Displacement capacity | Specified Pressure | Rotating Speed | Motor Power | Weight | Overrall Size (L*W*H) |
| m3/h | Mpa | r/min | KW | Kg | mm | ||
| HC-65A | Vertical type water cooled two stage compression piston type | 69 | 3.0 | 750 | 18.5 | 700 | 1430*900*1260 |
| 82 # | 900 | 22 | |||||
| 90 | 960 | 22 | |||||
| HC-265A | 137 | 750 | 37 | 1400 | 1870*1000*1180 | ||
| 170# | 900 | 45 | |||||
| 190 | 960 | 45 | |||||
| Remarks: # On behalf of 440V Suitable for 1.0 -3.0 cube air bottle | |||||||
