Key Eye Point-S - Image 1

Key Eye Point-S

Category: Blots and nuts

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote

We can supply according to your requirement.

Key Eye Point-S

China Key Eye Point-S:

Key Eye Point-S

Metric Thread:

ITEM NO.	WLL/T	M	Dimensional Parameters/mm											Locking Torque/ Nm		Kg
ITEM NO.	WLL/T	M	E	A	B	C	D	F	J	H	W	G	S	Locking Torque/ Nm		Kg
BLT094S-M39	7	M39x4.0	54	106	73	30	26.5	76	116	31	126	72	22	300-600		4
BLT094S-M42	9	M42x4.5	63	122	83	35	32	89	137	33	147	83	22	350-800		5.6
BLT094S-M45	9	M45x4.5	63	122	83	35	32	89	137	33	147	83	22	350-800		6.2
BLT094S-M48	12	M48x5.0	72	141.5	95	39	38	105	151	36	168	95	27	350-800		8.6
BLT094S-M52	12	M52x5.0	72	141.5	95	39	38	105	151	36	168	95	27	350-800		9.6
BLT094S-M56	16	M56x5.5	84	164	110	49	48	125	180	49	196	110	27	350-800		14.5
BLT094S-M60	16	M60x5.5	84	164	110	49	48	125	180	49	196	110	27	350-800		14.8
BLT094S-M64	18	M64x6.0	96	164	110	49	48	125	180	49	196	110	27	350-800		15.2

UNC Thread:

ITEM NO.	WLL/T	M	TPI	Dimensional Parameters/mm											Locking Torque/ Nm		Kg
ITEM NO.	WLL/T	M	TPI	E	A	B	C	D	F	J	H	W	G	S	Locking Torque/ Nm		Kg
BLT094S-5/16	0.3	5/16	18	12	36.5	25	10	10	25	41	5	44	25	6	10-40		0.18
BLT094S-3/8	0.4	3/8	16	15	36.5	25	10	10	25	41	5	44	25	6	10-40		0.28
BLT094S-1/2	0.75	1/2	13	18	44.5	30	11	11	33	47	7	52	30	8	15-40		0.43
BLT094S-5/8	1.5	5/8	11	24	50.5	35	15	13	36	58	10	61	34	10	45-130		0.63
BLT094S-3/4	2.3	3/4	10	30	58	40	17	15	44	68	13	70	39	12	45-130		0.73
BLT094S-7/8	2.3	7/8	9	30	58	40	17	15	44	68	13	70	39	12	100-170		0.73
BLT094S-1	3.2	1	8	36	71	49	20	17.5	53	75	14	84	48	14	190-280		1.13
BLT094S-1-1/4	4.5	1-1/4	7	45	88	61	25	22	66	95	20	105	60	17	270-600		2.16
BLT094S-1-1/2	7	1-1/2	6	54	106	73	30	26.5	76	116	28	126	72	22	270-600		3.9
BLT094S-1-3/4	9	1-3/4	5	63	122	83	35	32	89	137	33	147	83	22	350-800		5.6
BLT094S-2	12	2	4.5	72	141.5	95	39	38	105	151	36	168	95	27	350-800		8.9
BLT094S-2-1/4	16	2-1/4	4.5	84	164	110	49	48	125	180	49	196	110	27	350-800		15
BLT094S-2-1/2	18	2-1/4	4	96	164	110	49	48	125	180	49	196	110	27	350-800		15.2
