BLT082S Heavy Duty Hoist Ring-S - Image 1

BLT082S Heavy Duty Hoist Ring-S

Category: Blots and nuts

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote

We can supply according to your requirement.

BLT082S Heavy Duty Hoist Ring-S

China BLT082S Heavy Duty Hoist Ring-S:

BLT082S Heavy Duty Hoist Ring-S

Metric Thread:

ITEM NO.	WLL/T	M	Dimensional Parameters/mm											Locking Torque/Nm		Kg
ITEM NO.	WLL/T	M	E	A	B	C	D	F	G	H	R	S	SW	Locking Torque/Nm		Kg
BLT082S-M6	0.2	M6x1.0	12	33	58	36	10	84	30	10	15.5	6	13	10		0.3
BLTO82S-M8	0.5	M8x1.25	12	33	58	36	10	84	30	10	15.5	6	13	10		0.3
BLTO82S-M10	0.7	M10x1.5	15	33	58	36	10	84	30	10	15.5	6	13	10		0.3
BLT082S-M12	1	M12x1.75	20	33	58	36	10	84	30	10	15.5	6	13	15		0.35
BLTO82S-M14	1.5	M14x2.0	21	50	90	50	15	126	44.5	18	22	8	19	30		1.15
BLTO82S-M16	2	M16x2.0	24	50	90	50	15	126	44.5	18	22	8	19	50		1.2
BLT082S-M18	2.5	M18x2.5	26	65	117	66	22	163	58	21	29.5	10	27	70		2.6
BLT082S-M20	3	M20x2.5	30	65	117	66	22	163	58	21	29.5	10	27	100		2.65
BLT082S-M22	4	M22x2.5	33	65	117	66	22	163	58	21	29.5	10	27	100		2.7
BLT082S-M24	5	M24x3.0	36	65	117	66	22	163	58	21	29.5	10	27	160		2.75
BLT082S-M27	5.6	M27x3.0	38	87	147	80	26.5	206	76.5	28	35.5	14	34	200		5.45
BLT082S-M30	7.8	M30x3.5	48	87	147	80	26.5	206	76.5	28	35.5	14	34	500		5.8
BLT082S-M33	8.3	M33x3.5	48	87	147	80	26.5	206	76.5	28	35.5	14	34	500		5.7
