ZYC23LED LED Pendant Light
The scope of application
This series of lights fit for illumination for the places of ships with water dripping, water spattering, water coagulating(such as weather place, such as oven cabin, dry cabin, tunnel, pipeline and weather deck etc.).
Products feature
1.The shell adopts good quality cold-rolled plate by mold pressing ,surface is powder coated after anti-acid white.
2. The lampshade is made of transparent impact resistant poly carbonate plastic by injection forming, Lampshade seal-ring use foamed silicone rubber, with good sealed performance.
3. In order to ensure the safety of electricity, both inside and outside of lamps is equipped with "" Connection Bridge.
4. Adopt LED light source with long working life, high intensity, and low energy consumption.
5. Equipped with 24V / 1.5W LED emergency light source, as temporary lighting when power off. 6. With emergency lamp holder lights, on the lampshade with a red remark
7. The cable outside diameter is Φ11～Φ13mm.
Adopt standard
1. Conform to IEC60598-1-2008 INTERNATIONAL STANDARD.
2. Conform to Rules for the classification of sea-going steel ships.
3. Approved by type approval of China Classification Society (CCS).
Installation
ZYC23LED LED Pendant Light Specification
| Type | ZYC23LED | ||
| Voltage(V) | 220V | ||
| Light Source | LED | ||
| Power(W) | 12 | ||
| Protection Class | IP44 | ||
| Weight( Kg) | 4.8 | ||
