NEK606 Power and Control Cables P18 RU 0.6/1kV
Category:
NEK 606 Offshore & Marine Cables
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
NEK606 Power and Control Cables P18 RU 0.6/1kV:
Description

P18 RU 0.6/1kV Marine cables are flame retardant, low smoke, halogen freeand mud resistant, used for control, power and lighting systems.

Standards

IEC 60092-353

IEC 60092-351

IEC 60092-359

IEC 60332-1

IEC 60332-3-22

IEC 60754-1,2

IEC 61034-1,2

NEK 606:2004

Construction
  • Conductors : Tinned annealed stranded copper to IEC 60228 class 2.
  • Insulation : Halogen-free EPR.
  • Outer Sheath :Halogen free thermosetting compound, SHF2, coloured black.
Technical data

Nominal Cross Section Area mm² 1.5 2.5 4 6 10 16 25 35
Nominal Conductor Diameter mm 1.6 2.1 2.6 3.2 4 5.1 6.5 7.4
Maximum DC Resistant@20℃ Ω/km 12.2 7.56 4.7 3.11 1.84 1.16 0.734 0.529
Continuous Current Rating@45℃1 Core A 23 30 40 52 72 96 127 157
Continuous Current Rating@45℃2 Core A 20 26 34 44 61 82 108 133
Continuous Current Rating@45℃3&4 Core A 16 21 28 36 50 67 89 110
Short Circuit Current 1s A 210 360 570 860 1430 2290 3580 5010
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1
Nominal Cross Section Area mm² 50 70 95 120 150 185 240 300
Nominal Conductor Diameter mm 8.7 10.3 12.2 13.8 15.1 17 19.6 21.9
Maximum DC Resistant@20℃ Ω/km 0.391 0.27 0.195 0.154 0.126 0.1 0.0762 0.0607
Continuous Current Rating@45℃1 Core A 196 242 293 339 389 444 522 601
Continuous Current Rating@45℃2 Core A 167 206 249 288 331 444 444 511
Continuous Current Rating@45℃3&4 Core A 137 169 205 237 272 311 365 421
Short Circuit Current 1s A 7150 10020 13590 17170 21460 26470 34340 42930
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1

Mechanical and Thermal Properties
  • Bending Radius : 8×OD (during installation); 6×OD (fixed installed).
  • Temperature Range : -20℃ ~ +90℃.
