Marine Bronze Three Way Valve JIS F7381
Category:
JIS Marine Valve
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Marine Bronze Three Way Valve JIS F7381:
China Marine Bronze Three Way Valve JIS F7381:

Marine Bronze Flanged Cock JIS F7381 has two-way cock and three-way cock. And for three-way cock, there are L type and T type. It is used on the marine pipe system of water supply, fuel oil and lubrication oil. Marine Cock is also called as marine plug valve, plug cock, it is used to control the opening and closing of the pipe system, and also adjust the flow rate. Three-way cock is used mostly, adapted to the three channel structure.

Technical Specification:

Design and Manufacturing Standard: JIS F7381-1996

Test Standard: JIS F7400-1996

Hydraulic Test Pressure: Body-0.75Mpa, Plug-0.55Mpa

Flange Standard: JIS B2220 5K

Max Working Pressure: 0.5Mpa

Suitable Medium: water, oil.

Main Material:

Body: Bronze

Plug: Bronze

Main Data for Joining(mm):

IMPA CODE Size L L1 D C No h t H D2 Weight
Two-Way
751601 25 130 - 95 75 4 12 10 105 160 3.13
751602 32 160 - 115 90 4 15 12 125 180 5.02
751603 40 170 - 120 95 4 15 12 135 190 6.66
751604 50 190 - 130 105 4 15 14 163 200 10
751605 65 220 - 155 130 4 15 14 201 250 16.7
L-Type Three-Way
751606 25 130 - 95 75 4 12 10 105 160 3.81
751607 32 160 - 115 90 4 15 12 125 180 6.13
751608 40 170 - 120 95 4 15 12 135 190 7.93
751609 50 190 - 130 105 4 15 14 163 200 11.8
751610 65 220 - 155 130 4 15 14 201 250 19
T-Type Three-Way
751612 25 130 - 95 75 4 12 10 105 160 3.81
751613 32 160 - 115 90 4 15 12 125 180 6.13
751614 40 170 - 120 95 4 15 12 135 190 7.93
751615 50 190 - 130 105 4 15 14 163 200 11.8
751616 65 220 - 155 130 4 15 14 201 250 19
