CV-30/30 Marine air compressor
Category:
Marine Medium Pressure Water-cooled Series Air Compressor
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
CV-30/30 Marine air compressor:
Models: CV-30/30 Marine air compressor

Type: V type, two columns, water-cooled, medium pressure piston, elastic coupling straight league transmission

Displacement: 30.0 m3 / h

The rated pressure: 3.0 MPa

Product features

1.Compact structure, highly efficient, light weight, small volume, low noise, low exhaust temperature, smooth operation;

2. Applicable to the ship host and various medium-sized diesel engine start, can also be used for hydropower station of brake, all kinds of valves, instrumentation, container pressure testing and other needs 1.5 ~ 3.0 MPa gas source of various industrial sectors.

3. According to the needs of users of products can provide the following functions: two main for the functions of each control, temperature control, inlet pressure controller, exhaust outlet high pressure hose.

Main Technical Parameter

Model Displacement Specified Rotating Motor Power Dimension (L×W×H) Weight
Pressure Speed
m3/h m3/ min MPa r/min kW HP mm kg
CZ-20/30SZK 20 0.34 3.0 960 5.5 7.5 900×600×850 250
CZ-20/30SZK 1000 1070×490×810 225
CV-30/30 30 0.5 720 7.5 10 1230×730×690 330
CV-40/30 40 0.67 870 11 15 1230×730×690 340
CV-50/30 50 0.83 970 11 15 1230×730×690 340
CV-90/30 90 1.5 730 22 30 1600×1010×1050 900
CV-120/30 120 2 975 30 40 1600×1010×1050 1000
