Armoured PROFIBUS 1 Pair 22 AWG Communication Cables
Basic Parameters
Cable Feature: These profibus cables are dedicated for fixed installation on board of ship, used as connection cables for digital signals up to 12MBd.
Bending Radius: 10×OD
Temperature Range: -30℃ ~ +75℃
Stanards
IEC 60332-1&2
IEC 60754-1/2
IEC 61034
IEC 60092
Construction
Conductors: Stranded bare copper 22 AWG.
Insulation: Foam skin PE.
Easy Strip: Thermoplastic copolymer (FRNC).
Overall Screen1: Aluminium/polyester tape.
Overall Screen2: Tinned copper braid.
Inner Sheath: SHF2.
Armour: Galvanised Steel Wire Braid.
Outer Sheath: SHF2.
