A1.0-3 Marine Air receiver
Description:
A type : A1.0-3 Marine Air receiver
A vertical or inclination.
Marine Low-pressure air receiver is mainly used to store compressed air, and supply start up or air whistle for main engine and auxiliary engine.
A- type is made up of bottle valve and steel body. Body has handhole (or manhole) foe easy wash and examination, and bottle valve set up inlet/outlet valve, safety valve , pressure gauge and pressure gauge valve, drain valve etc.
| Type | Type remark | Capacity |
Working Pressure Mpa |
Internal Diameter mm |
Height mm |
Weight kg |
| A Type | A0.05-1.0 | m3 | 1 | 300 | 1050 | 70 |
| A0.10-1.0 | 0.1 | 400 | 1270 | 125 | ||
| A0.16-1.0 | 0.16 | 400 | 1750 | 155 | ||
| A0.25-1.0 | 0.25 | 500 | 1760 | 180 | ||
| A0.32-1.0 | 0.32 | 500 | 2170 | 248 | ||
| A0.40-1.0 | 0.4 | 600 | 1865 | 250 | ||
| A0.05-3.0 | 0.05 | 3 | 300 | 1050 | 100 | |
| A0.08-3.0 | 0.08 | 300 | 1360 | 120 | ||
| A0.10-3.0 | 0.1 | 400 | 1270 | 165 | ||
| A0.16-3.0 | 0.16 | 400 | 1750 | 215 | ||
| A0.25-3.0 | 0.25 | 500 | 1760 | 295 | ||
| A0.32-3.0 | 0.32 | 500 | 2100 | 345 | ||
| A0.40-3.0 | 0.4 | 600 | 1865 | 410 | ||
| A0.50-3.0 | 0.5 | 600 | 2270 | 450 |
| B Type | Type remark |
Capacity m3 |
Working Pressure Mpa |
Internal Diameter mm |
Height mm |
Weight kg |
| B0.63-1.0 | 0.63 | 1 | 700 | 1370 | 480 | |
| B0.80-1.0 | 0.8 | 700 | 1370 | 520 | ||
| B1.00-1.0 | 1 | 800 | 1490 | 695 | ||
| B0.63-3.0 | 0.63 | 3 | 700 | 1470 | 680 | |
| B0.80-3.0 | 0.8 | 700 | 1470 | 780 | ||
| B1.00-1.0 | 1 | 800 | 1580 | 950 | ||
| B1.60-3.0 | 1.6 | 900 | 1680 | 1180 | ||
| B2.50-3.0 | 2.5 | 1100 | 1940 | 1925 | ||
| B4.00-3.0 | 4 | 1200 | 2040 | 3400 | ||
| B4.50-3.0 | 4.5 | 1200 | 2040 | 3750 | ||
| B5.00-3.0 | 5 | 1200 | 2040 | 4100 | ||
| B6.30-3.0 | 6.3 | 1400 | 2266 | 4230 | ||
| B8.00-3.0 | 8 | 1500 | 2365 | 4930 | ||
| B10.00-3.0 | 10 | 1600 | 2505 | 6785 | ||
| B12.00-3.0 | 12 | 1700 | 2605 | 7500 | ||
| B14.00-3.0 | 14 | 1800 | 2750 | 8770 | ||
| B16.00-3.0 | 16 | 2000 | 3070 | 11000 |
