NEK606 P34 BFOU-HCF 0.6/1 kV cables

Description

This P34 BFOU-HCF 0.6/1 kV cables are fire resistant, flame retardant, low smoke and halogen free, used for emergency control, power and lighting systems that need to be operational during a 1100℃ hydrocarbon fire.

Standards

IEC 60092-353

IEC 60092-351

IEC 60092-359

IEC 60332-1

IEC 60332-3-22

IEC 60754-1,2

IEC 61034-1,2

NEK 606:2004

Construction
  • Conductors : Tinned annealed stranded compacted copper to IEC 60228 class 2.
  • Insulation : Mica tape + Halogen free EPR/XLPE.
  • Bedding : Halogen free compound.
  • Armour : Tinned copper wire braid.
  • Outer Sheath1 : Halogen free thermosetting compound, SHF2.
  • HC-fire protection : Extruded thermoplastic fire protection compound.
  • Taping : Lapped glass fibre tape.
  • Outer Sheath2 : Flame retardant halogen-free thermoplastic compound, SHF1, coloured black.
Technical data

Nominal Cross Section Area mm² 1.5 2.5 4 6 16 35
Nominal Conductor Diameter mm 1.6 2.1 2.6 3.2 5.1 7.4
Maximum DC Resistant@20℃ Ω/km 12.2 7.56 4.7 3.11 1.16 0.529
Continuous Current Rating@45℃1 Core A 23 30 40 52 96 157
Continuous Current Rating@45℃2 Core A 20 26 34 44 82 133
Continuous Current Rating@45℃3&4 Core A 16 21 28 36 67 110
Short Circuit Current 1s A 210 360 570 860 2290 5010
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1
Nominal Cross Section Area mm² 50 70 95 120 150 185 240 300
Nominal Conductor Diameter mm 8.7 10.3 12.2 13.8 15.1 17 19.6 21.9
Maximum DC Resistant@20℃ Ω/km 0.391 0.27 0.195 0.154 0.126 0.1 0.0762 0.0607
Continuous Current Rating@45℃1 Core A 196 242 293 339 389 444 522 601
Continuous Current Rating@45℃2 Core A 167 206 249 288 331 444 444 511
Continuous Current Rating@45℃3&4 Core A 137 169 205 237 272 311 365 421
Short Circuit Current 1s A 7150 10020 13590 17170 21460 26470 34340 42930
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1

Mechanical and Thermal Properties
  • Bending Radius :20×OD (during installation); 12×OD (fixed installed).
  • Temperature Range : -20℃ ~ +90℃.
