Miniature electric hoist
Miniature electric hoist
The miniature electric hoist adopts 220V civil power supply, which is especially suitable for daily civil, industrial production lines, freight logistics and other occasions.
Product advantages
Shell: A3 steel is refined, beautiful in appearance, sturdy and durable.
Motor: Full copper wire wound movement, fast heat dissipation, high temperature resistance, 220V voltage.
Gear: high-quality hardened gear, high hardness, good toughness and durability.
Switch: High quality insulated switch, can be used with a radio remote control.
Hook: Advanced alloy steel hook, equipped with anti-collision protection, designed with advanced single and double hook settings, greatly increasing the lifting weight of the miniature electric hoist.
Technical Specification
| Weight(kg) | Lifting Height(m) | Lifting speed(m/min) | Power(w) | Voltage(V) | Frequency(HZ) | Net weight(kg) | Supporting capacitor(µF) | Wire rope diameter(mm) |
| 100/200 | 12/6 | 10/5 | 510 | 220 | 50 | 11 | 16 | 3 |
| 125/250 | 12/6 | 10/5 | 550 | 220 | 50 | 11 | 18 | 3 |
| 150/300 | 12/6 | 10/5 | 600 | 220 | 50 | 11.5 | 25 | 3 |
| 200/400 | 12/6 | 10/5 | 980 | 220 | 50 | 16 | 30 | 4 |
| 250/500 | 12/6 | 10/5 | 1020 | 220 | 50 | 16 | 35 | 4 |
| 300/600 | 12/6 | 10/5 | 1200 | 220 | 50 | 17 | 40 | 4.5 |
| 400/800 | 12/6 | 10/5 | 1300 | 220 | 50 | 18.5 | 45 | 5 |
| 500/1000 | 12/6 | 8/4 | 1600 | 220 | 50 | 31 | 60 | 6 |
