Marine Bronze/Brass Screw Down Check Angle Valve JIS F7352 5K
Category:
JIS Marine Valve
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Marine Bronze/Brass Screw Down Check Angle Valve JIS F7352 5K:
China Marine Bronze/Brass Screw Down Check Angle Valve JIS F7352 5K:

Marine Screw Down Check Angle Valve is angle SDNR valve, angle stop check valve, used on the marine pipe system whose angle between inlet and outlet is 90 degree to open or close the pipe system and control the flow rate and prevent the medium backflow. Marine Bronze/Brass Screw Down Check Angle Valvecan be used for sea water, fresh water, fuel oil, lubrication oil & Steam pipe system.

If the size is DN10~DN40, the bonnet is screwed type, if the size is DN50 and bove DN50, the bonnet is bolted type.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7352

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 5K

5.Hydraulic Pressure Test: Body-1.05Mpa, Seat-0.77Mpa

6. Max Working Pressure: 0.5Mpa for air, gas, oil, pulsation water and steam of 205℃ or less, 0.7Mpa for non-shock water of 120℃ or less

7. Warranty: 12months

8. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Bonnet:Bronze / Brass

5-Handwheel: Cast Iron (HT200)

Main Data for Joining(mm):

IMPA Code Size L1 D C No of Bolt Hole h t H D2
751061 15 55 80 60 4 12 9 120 80
751062 20 60 85 65 4 12 10 130 100
751063 25 65 95 75 4 12 10 145 125
751064 32 80 115 90 4 15 12 150 125
751065 40 85 120 95 4 15 12 165 140
751066 50 100 130 105 4 15 14 200 140
751067 65 115 155 130 4 15 14 220 160
