Marine Bronze/Brass Angle Hose Valve JIS F7334B 5K
Category:
JIS Marine Valve
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Marine Bronze/Brass Angle Hose Valve JIS F7334B 5K:
China Marine Bronze/Brass Angle Hose Valve JIS F7334B 5K:

Marine Angle Hose Valve is straight fire hydrant used in the ship. It controls the opening/closing of fire fighting water, the fire hose and nozzle are connected with the hose valve for fire-fighting.

If the nominal size is DN15 and DN25, it is the screwed bonnet. If the nominal size is DN40 and DN50 it is bolted bonnet.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7334

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 5K

5.Hydraulic Pressure Test: Body-1.05Mpa, Seat-0.77Mpa

6. Max Working Pressure: 0.5Mpa for pulsation water, ari and steam of 205℃ or less, 0.7Mpa for non-shock water of 120℃ or less.

7. Warranty: 12months

8. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Coupling: Brass

Main Data for Joining(mm):

IMPA CODE DN L L1 D C No. h t H D2 D3
751706 15 68 55 80 60 4 12 9 129 80 M42x2
751708 25 78 65 95 75 4 12 10 161 125 M42x2
751713 40 124 85 120 95 4 15 12 193 140 M52x2
751721 50 155 100 130 105 4 15 14 256 160 M64x2
