Marine Bronze/Brass Screw Down Check Angle Valve JIS F7410 16K
JIS Marine Valve
FOB Price:
Get Latest Price Now
12 Months unless specified otherwise
Place of Origin:
Request a Quote Print this page
We can supply according to your requirement.
Marine Bronze/Brass Screw Down Check Angle Valve JIS F7410 16K:
China Marine Bronze/Brass Screw Down Check Angle Valve JIS F7410 16K:

Marine Screw Down Check Angle Valve is angle SDNR valve, angle stop check valve, used on the marine pipe system whose angle between inlet and outlet is 90 degree to open or close the pipe system and control the flow rate and prevent the medium backflow. Marine Bronze/Brass Screw Down Check Angle Valvecan be used for sea water, fresh water, fuel oil, lubrication oil & Steam pipe system.

If the size is DN10~DN40, the bonnet is screwed type, if the size is DN50 and bove DN50, the bonnet is bolted type.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7410

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 16K

5.Hydraulic Pressure Test: Body-3.3Mpa, Seat-2.42Mpa

6. Max Working Pressure: 1.6Mpa for air, gas, oil, pulsation water and steam of 205℃ or less, 2.2Mpa for non-shock water of 120℃ or less

7. Warranty: 12months

8. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Bonnet:Bronze / Brass

5-Handwheel: Cast Iron (HT200)

Main Data for Joining(mm):

IMPA CODE Size L D C No. of Bolt h t H D2
751081 15 70 95 70 4 15 12 120 80
751082 20 75 100 75 4 15 14 125 100
751083 25 85 125 90 4 15 14 140 125
751084 32 95 135 100 4 15 16 145 125
751085 40 100 140 105 4 19 16 160 140
