Manual hydraulic platform truck
Manual hydraulic platform truck
This series of platform trucks is a high-lifting handling tool for short-distance handling and lifting load-bearing range, as well as workbench in the workshop.
Technical Specification
| Type | PT150Z | PT300Z | PT500Z |
| Rated load(kg) | 150 | 300 | 500 |
| Minimum height(mm) | 210 | 280 | 250 |
| Maximum height | 720 | 900 | 900 |
| Platform size(mm) | 700*450*35 | 815*500*50 | 815*500*50 |
| Wheel diameter(mm) | φ100 | φ125 | φ125 |
| Self weight(kg) | 40 | 74 | 82 |
| Package size(mm) | 820*470*230 | 900*510*310 | 900*510*310 |
| Cylinder diameter(mm) | φ35 | φ40 | φ40 |
| Handle height from the ground(mm) | 880 | 1010 | 970 |
| 20-foot container packing(mm) | 192 | 144 | 144 |
