JISF2005 Closed Chock
JISF2005 Closed Chock
Description:
It is a popular type deck mounted type chock,made from cast steel,named as closed chock,can be finished in 7 to 15 days,it can be approval by main classification society,like ABS,LR,BV,NK,CCS etc.
Drawing:
Size Chart:
| Product No. | Dimension(mm) | Mass(kgs) | Dia. Of Rope Applied | |||||
| L | L1 | B | H | H1 | Wire | Hemp | ||
| DMJ-001 | 100 | 170 | 60 | 76 | 141 | 3.7 | 14 | 24 |
| DMJ-002 | 150 | 250 | 90 | 110 | 205 | 10.5 | 16 | 30 |
| DMJ-003 | 200 | 340 | 120 | 150 | 280 | 24 | 18 | 40 |
| DMJ-004 | 250 | 434 | 160 | 200 | 372 | 48 | 20 | 50 |
| DMJ-005 | 300 | 528 | 200 | 250 | 464 | 82 | 22 | 60 |
| DMJ-006 | 350 | 600 | 220 | 250 | 485 | 103 | 24 | 70 |
| DMJ-007 | 400 | 672 | 240 | 250 | 506 | 136 | 26 | 80 |
| DMJ-008 | 450 | 746 | 260 | 250 | 528 | 184 | 30 | 85 |
| DMJ-009 | 500 | 820 | 280 | 250 | 550 | 232 | 36 | 90 |
