JIS C 3410 250V TTYS FA-TTYS Telephone & Instumentation cable
Category:
JIS C 3410 Offshore & Marine Cables
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
JIS C 3410 250V TTYS FA-TTYS Telephone & Instumentation cable:
CABLE DESIGNATION

250V TTYS, FA- TTYS

250V TTYCS, FA- TTYCS

250V TTYCYS, FA- TTYCYS

APPLICATION STANDARD

- Design guide : JIS C 3410(1999)

- Flame retardant : IEC 60332-1 & IEC 60332-3 Category A (FA-Type)

- Cold bend/impact : CSA 22.2 No. 03 (-35℃ ) (Cold Type)

- Max. conductor temperature : 60℃

TECHNICAL DATA

1. CABLE TYPE:250V (FA-)TTYS, 250V (FA-)TTYCS, 250V (FA-)TTYCYS

No. of Pair, Triad or Quad: 1, 1T, 1Q, 2, 3, 4, 7, 10, 14, 19, 24, 30, 37, 48,

Nominal Area(mm2):2, 3, 4, 6, 8, 14, 20, 28, 38, 48, 60, 74, 96.

Classification Code Construction Detail
Conductor
TT Stranded plain annealed copper wires as per JIS C 3410.
Insulation PVC as per JIS C 3410.
Twisting Two Insulated cores shall be twisted together to form a pair
Cabling Twisted pairs shall be cabled.
Flame retardant & non-hygroscopic fillers may be used .
Suitable tape(s) may be applied on the cabled core.
Common shield S Tinned copper wire braid
Sheath Y PVC as per JIS C 3410.
Armor C Braid of galvanized steel wires.
Coverage density is minimum 90%.
Paint The white paint shall be painted uniformly on the steel wire braid
Protective covering Type, paint is dispensable.
Protective Covering Y PVC as per JIS C 3410.
Outer sheath color : Black
Core identification Printed pair number and Alphabet letter on the white insulation
ex) 4P : (1A,1B), (2A,2B), (3A,3B), (4A,4B)
1T, 1Q cable shall be identified by the black number on the white insulation
Note
Fire resistant type (“FRA-”) & Cold type cable (“(C)”) can be supplied.
