Hydraulic Azimuth Thruster
Product description:
The hydraulic thruster uses the hydraulic source as the driving power, and the propeller is driven directly by the hydraulic motor.
The utility model has the advantages of compact structure, convenient installation and maintenance, low cost, short production period, etc.
Its power range is 60HP-500HP.
Suitable for the yacht, opened mud ship and simple engineering ship etc.
Main technical parameters:
| Model | Power Rating | Dia of propeller | Thrust |
| (HP) | (mm) | (t) | |
| RFHP50 | 0-50 | 620 | 0-0.7 |
| RFHP100 | 50-100 | 830 | 1-1.4 |
| RFHP200 | 100-200 | 950 | 1.5-3.2 |
| RFHP300 | 200-300 | 1000 | 3.4-4.4 |
| RFHP400 | 300-400 | 1180 | 4.7-6.2 |
| RFHP500 | 400-500 | 1300 | 6.5-7.7 |
