CZF Marine Low Pressure Air Compressor
Product Description
1.Rating Pressure: 1.0 Mpa
2.Displacement capacity: 10-20 m3/h
3.Rotating Speed: 550-1100 rpm
4.Power: Electric Motor
5.Warranty: one year
Main Technical Parameter
| Model | Type | Displacement capacity | Specified Pressure | Rotating Speed | Motor Power | Overrall Size(L*W*H) |
| m3/h | Mpa | r/min | KW | mm | ||
| CZF-10/10 | Z type air cooled piston | 10 | 1.0 | 550 | 1.5 | 800*390*630 |
| CZF-15/10 | 15 | 880 | 2.2 | |||
| CZF-20/10 | 20 | 1100 | 3.0 | |||
| Suitable for service air bottles | ||||||
