CZF-3.5/1 Marine low pressure air compressor
CZF-3.5/1 Marine low pressure air compressor
Type: single, air-cooled, pistonDisplacement: 3.5 m3 /h
The rated pressure: 1.0 MPaProduct features
1. The product has a simple structure, small volume, low energy consumption, low noise, long service life
2. Type has a single row, V, W, the secondary compression piston.
3 .Low energy consumption, low noise, long service life.
4. Products with manual/automatic stop, start, unloading relief function.
5. Apply to ship whistle, oil and gas stove and ancillary equipment required for air.
6. Easy to maintenance.
Main Technical Parameter
|
Model |
Displacement Capacity（m3/h） |
Specified |
Rotating |
Motor Power |
Dimension（L×W×H）mm |
Weight（kg） |
|
|
kW |
HP |
||||||
|
CZF—3.5/1 |
3.5 |
1.0 |
810 |
0.75 |
1 |
650×390×580 |
58 |
