CWF-60/1 Marine low pressure air compressor
Model: CWF-60/1 Marine low pressure air compressor
Type: W, air cooled, two stage compression pistonDisplacement: 60 m3 / h
The rated pressure: 1.0 MPa
Product features
1. Type has a single row, V, W, the secondary compression piston.2. Low energy consumption, low noise, long service life.
3. Products with manual/automatic stop, start, unloading relief function.
4. Apply to ship whistle, oil and gas stove and ancillary equipment required for air.
5. Easy to maintenance.
Main Technical Parameter
| Model | Displacement Capacity（m3/h） | Specified | Rotating | Motor Power | Dimension（L×W×H）mm | Weight（kg） | |
| Pressure（MPa） | Speed（r/min） | kW | HP | ||||
| CWF—60/1 | 60 | 1.0 | 720 | 11 | 15 | 1340×660×960 | 360 |
