CWF-10/1 Marine low pressure air compressor
Model: CWF-10/1 Marine low pressure air compressor
Type: Vertical and horizontal, air cooled, two stage compression piston
Displacement: 10.0 m3 /hThe rated pressure: 1.0 MPa
Product features
1. Type has a single row, V, W, the secondary compression piston.2. Small size, light weight; Low energy consumption, low noise, long service life.
3. Products with manual/automatic stop, start, unloading relief function.
4. Apply to ship whistle, oil and gas stove and ancillary equipment required for air.
5. Easy to maintenance.
Main Technical Parameter
| Model | Displacement Capacity（m3/h） | Specified | Rotating | Motor Power | Dimension（L×W×H）mm | Weight（kg） | |
| Pressure（MPa） | Speed（r/min） | kW | HP | ||||
| CWF-10/1(Vertical) | 10 | 1.0 | 750 | 1.5 | 2 | 500×400×740 | 85 |
| CWF—10/1(Horizontal) | 10 | 1.0 | 750 | 1.5 | 2 | 900×400×650 | 93 |
