CZ Marine Low Pressure Piston Air Compressor
Product Description
1.Type: CZ Marine Low Pressure Piston Air Compressor
2.Capacity:2.2~25.0 M3/h.
3.Rating Pressure:1.0 Mpa.
3.Rotating speed:750~800r/min.
4. Certificate,CCS,RINA,KR,BV etc.
Main Technical Parameter
| Model No. | Type | Discharge Capacity m3/h | Discharge Pressure kgf/cm2 | Speed r/min | Motor Power KW | Overall Site (L×W×H) | Weight (kg) |
| KY5-002 | CZ-2.2/10F | 2.2 | 10 | 750 | 0.75 | 520×320×350 | 42 |
| KY5-003 | CZ-2.2/10F | 2.2 | 10 | 750 | 0.75 | 740×350×620 | 52 |
| KY6-003 | CZ-5/10FZK | 5 | 10 | 750 | 1.5 | 710×360×460 | 90 |
| KY6-002 | CZ-6/10FZK | 6 | 10 | 750 | 1.5 | 710×360×460 | 90 |
| KY7-004 | CZ-10/10FZK | 10 | 10 | 750 | 2.2 | 790×410×530 | 120 |
| KY7-003 | CZ-15/10FZK | 15 | 10 | 750 | 3 | 790×410×530 | 125 |
| KY9-002 | CZ-20/10FZK | 20 | 10 | 800 | 4 | 850×470×630 | 190 |
| KY9-003 | CZ-25/10FZK | 25 | 10 | 750 | 4 | 850×470×680 | 190 |
