CZ-5/30FZK Marine air compressor
Model: CZ-5/30FZK Marine air compressor
Type: single row, air-cooled, two step piston type
Exhaust volume: 5.0 m3/h
Rated pressure: 3 MPa
It has the advantages of simple structure, high efficiency, light weight, small volume, low noise, stable operation; suitable for marine engine and various medium-sized diesel engine starting purposes, can also be used for hydro power station braking, various types of valves, instruments, pressure test and other fields as a source of pressure strength. Products according to user needs can provide the following functions: two machine main ready for mutual control function, temperature control function, import pressure controller, exhaust outlet high-pressure hose.
Product features
1.The type of single row, double row, V type, W type, two stage compression piston.
2.With the high efficiency, light weight, small volume, low noise, stable operation
3.The product has a manual / automatic stopping, starting and unloading relief function.
Main Technical Parameter
| Model | Displacement | Specified | Rotating | Motor Power | Dimension（L×W×H） | Weight | ||
| Pressure | Speed | |||||||
| m3/h | m3/ min | MPa | r/min | kW | HP | mm | kg | |
| CZ-5/30FZK | 5 | 0.08 | 3 | 520 | 2.2 | 3 | 970×480×750 | 170 |
