Cat 6 SF/UTP 24AWG 4P/8P Communication Cables

Cat 6 SF/UTP 24AWG 4P/8P Communication Cables

Basic Parameters

Cable Feature: support all Class E applications like Ethernet, Fast Ethernet, Gigabit Ethernet, suitable for basic voice and data installations up to 250MHz.

Bending Radius: 8×OD (during installation); 4×OD (fixed installed)

Temperature Range: -20℃ ~ +60℃

Stanards

EN 50288 ISO 11801

IEC 61156-5 IEC 60332-1

IEC 60754-1/2 IEC 61034

Construction

Central Cross

Conductors: Solid bare copper conductor.

Insulation: Foam skin PE.

Twinning: Two coloured insulated conductors twisted together to form a pair.

Overall Screen1: Al/polyester tape.

Overall screen2: Tinned copper wire braid.

Outer Sheath: Polyolefin.
