5t Wire rope electric hoist
5t Wire rope electric hoist
It can be used on straight, curved, circulating overhead tracks on the same plane, or on cranes such as electric single beams, manual single beams, cantilever, gantry cranes, etc. This series of electric hoists are widely used in factories, warehouses, terminals, power stations, ships and other occasions.
Product advantages
The utility model has the advantages of light weight, small volume, compact structure, variety and specifications, stable operation, simple operation and convenient use.
Technical Specification
| Load(t) | 0.5 | 1 | 2 | 3 | 5 | 10 | ||||||||||||||||||||||||||
| Lifting height(m) | 6 | 9 | 12 | 6 | 9 | 112 | 18 | 24 | 30 | 6 | 9 | 112 | 18 | 24 | 30 | 6 | 9 | 112 | 18 | 24 | 30 | 6 | 9 | 112 | 18 | 24 | 30 | 9 | 112 | 18 | 24 | 30 |
| Lifting speed(m/min) | 8 | 8 | 8 | 8 | 8 | 7 | ||||||||||||||||||||||||||
| Running speed(m/min) | 20(30) | 20(30) | 20(30) | 20(30) | 20(30) | 20(30) | ||||||||||||||||||||||||||
| Wire rope diameter(mm) | 4.8 | 7.4 | 11 | 13 | 15 | 15 | ||||||||||||||||||||||||||
| I-beam track | 16-28b | 16-28b | 20a-32c | 20a-32c | 25a-63c | 25a-63c | ||||||||||||||||||||||||||
| Lifting motor power(kw) | 0.8 | 1.5 | 3 | 4.5 | 7.5 | 13 | ||||||||||||||||||||||||||
| Running motor power(kw) | 0.2 | 0.5 | 0.4 | 0.4 | 0.8 | 0.8 | ||||||||||||||||||||||||||
| Weight(kg) | 121 | 125 | 130 | 137 | 145 | 172 | 188 | 204 | 220 | 221 | 232 | 285 | 309 | 332 | 353 | 281 | 297 | 354 | 390 | 420 | 451 | 473 | 495 | 597 | 646 | 686 | 726 | 1048 | 1098 | 1209 | 1310 | 1411 |
