SUB series Vane pump
SUB series Vane pump
SUB series pump is positive displacement vane pump, applied to transfer gasoline, kerosene, diesel and other light oil, used to load and unload in stock termincal, also on oil tank trucks and mobile fuel unit.
Technical parameter:
| Model | SUB-40 | SUB-50 | SUB-80 |
| Size | 40mm/1-1/2" | 50mm/2" | 80mm/3" |
| Speed (RPM) | 1400 | 1400 | 960 |
| Flow rate (L/min) | 180 | 250 | 500 |
| Vacuum | 0.06MPA | 0.06MPA | 0.06MPA |
| Working pressure | 6Bar | ||
| Power(kw) | 2.2 | 2.2 | 7.5 |
