NEK606 P5 or P5/P12 BFOU 0.6/1KV cables

Category: NEK 606 Offshore & Marine Cables
Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS
FOB Price: Get Latest Price Now
Warranty: 12 Months unless specified otherwise
Place of Origin: China
Request a Quote Print Page Dowdload Page

We can supply according to your requirement.

NEK606 P5 or P5/P12 BFOU 0.6/1KV cables

Description:

NEK606 standard P5 or P5/P12 BFOU 0.6/1KV cables are fire resistant, flame retardant, low smoke,halogen free and mud resistant, used for control, power and lighting systems.

Standards

IEC 60092-353

IEC 60092-351

IEC 60092-359

IEC 60332-1

IEC 60332-3-22

IEC 60754-1,2

IEC 61034-1,2

NEK 606:2004

Construction
  • Conductors: Tinned annealed stranded compacted copper to IEC 60228 class 2.
  • Insulation: Mica tape + Halogen free EPR.
  • Bedding: Halogen free compound.
  • Armour: Tinned copper wire braid.
  • Outer Sheath: Halogen free thermosetting compound, SHF2 (for TYPE P5). Halogen free, mud resistant thermosetting compound, SHF MUD (for TYPE P5/P12), coloured black.
Technical data

Nominal Cross Section Area mm² 1.5 2.5 4 6 10 16 25 35 50
Nominal Conductor Diameter mm 1.6 2.1 2.6 3.2 4 5.1 6.5 7.4 8.7
Maximum DC Resistant@20℃ Ω/km 12.2 7.56 4.7 3.11 1.84 1.16 0.734 0.529 0.391
Continuous Current Rating@45℃1 Core A 23 30 40 52 72 96 127 157 196
Continuous Current Rating@45℃2 Core A 20 26 34 44 61 82 108 133 167
Continuous Current Rating@45℃3&4 Core A 16 21 28 36 50 67 89 110 137
Short Circuit Current 1s A 210 360 570 860 1430 2290 3580 5010 7150
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1
Nominal Cross Section Area mm² 70 95 120 150 185 240 300 400 630
Nominal Conductor Diameter mm 10.3 12.2 13.8 15.1 17 19.6 21.9 24.6 32.5
Maximum DC Resistant@20℃ Ω/km 0.27 0.195 0.154 0.126 0.1 0.0762 0.0607 0.0475 0.0286
Continuous Current Rating@45℃1 Core A 242 293 339 389 444 522 601 690 890
Continuous Current Rating@45℃2 Core A 206 249 288 331 444 444 511 587 757
Continuous Current Rating@45℃3&4 Core A 169 205 237 272 311 365 421 483 623
Short Circuit Current 1s A 10020 13590 17170 21460 26470 34340 42930 57230 90140
Operating Voltage KV 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1 0.6/1

Mechanical and Thermal Properties
  • Bending Radius : 8×OD (during installation); 6×OD (fixed installed).
  • Temperature Range : -20℃ ~ +90℃.
