NEK 606 Marine Cable P17 BU 0.6/1 kV

Category: NEK 606 Offshore & Marine Cables

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote

We can supply according to your requirement.

This Marine Cable P17 BU 0.6/1 kV are fire resistant, flame retardant, low smoke and halogen free, used for control, power and lighting systems.

Standards

Nominal Cross Section Area	mm²	1.5	2.5	4	6	10	16	25	35
Nominal Conductor Diameter	mm	1.6	2.1	2.6	3.2	4	5.1	6.5	7.4
Maximum DC Resistant@20℃	Ω/km	12.2	7.56	4.7	3.11	1.84	1.16	0.734	0.529
Continuous Current Rating@45℃1 Core	A	23	30	40	52	72	96	127	157
Continuous Current Rating@45℃2 Core	A	20	26	34	44	61	82	108	133
Continuous Current Rating@45℃3&4 Core	A	16	21	28	36	50	67	89	110
Short Circuit Current 1s	A	210	360	570	860	1430	2290	3580	5010
Operating Voltage	KV	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1
Nominal Cross Section Area	mm²	50	70	95	120	150	185	240	300
Nominal Conductor Diameter	mm	8.7	10.3	12.2	13.8	15.1	17	19.6	21.9
Maximum DC Resistant@20℃	Ω/km	0.391	0.27	0.195	0.154	0.126	0.1	0.0762	0.0607
Continuous Current Rating@45℃1 Core	A	196	242	293	339	389	444	522	601
Continuous Current Rating@45℃2 Core	A	167	206	249	288	331	444	444	511
Continuous Current Rating@45℃3&4 Core	A	137	169	205	237	272	311	365	421
Short Circuit Current 1s	A	7150	10020	13590	17170	21460	26470	34340	42930
Operating Voltage	KV	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1	0.6/1

Mechanical and Thermal Properties
