MFX400 Multicore Fire Barriers HEPR Insulated Screened Fire Resistant Cables:

Basic Parameters

Cable Feature: Fire Barriers + HEPR insulated, Screened,fire resistant, flame retardant, low smoke & halogen free.

Bending Radius: 6×OD

Temperature Range: -20℃ ~ +75℃

Standards

DIN 89160/98, IEC 60092-353, IEC 60331-21, IEC 60332-1, IEC 60332-3-22, IEC 60754-1/2, IEC 61034

Construction

Conductors: Class 2 stranded copper conductor.

Insulation: Fire barriers + HEPR.

Inner Covering: Lapping or extruded filler.

Overall Screen: Copper wire braid.

Outer Sheath: LSOH (SHF1).
