Marine Ductile Iron Globe Valve JIS F7321 5K
China Marine Ductile Iron Globe Valve JIS F7321 5K:
Marine Ductile Iron Globe Valve is the stop valve made of nodular iron, the price is cheaper compared with bronze valve, can replace the bronze valve in some small size pipe system.
Technical Specification:
Nominal Size: DN15~DN40
Design Standard: JIS F7312-1996
Test Standard: JIS 7400-1996
Hydraulic Test Pressure: Body-1.05Mpa, Seat-0.77Mpa
Flange Standard: JIS B2220 -5K
Main Material:
1.Body/Bonnet---Ductile Iron FCD450
2.Seat---SUS (SCS2) /Bronze (BC6)
3.Stem--SUS (SCS2) /Brass (C3771BD)
Main Size:
| IMPA CODE | SIZE | L | C | Hole | Weight (kg) |
| 750301 | 5K15 | 100 | 80 | 4 X D12 | 1.98 |
| 750302 | 5K20 | 110 | 85 | 4 X D12 | 2.8 |
| 750303 | 5K25 | 120 | 95 | 4 X D12 | 4.18 |
| 750304 | 5K32 | 140 | 115 | 4 X D15 | 5.53 |
| 750305 | 5K40 | 160 | 120 | 4 X D15 | 7.08 |
