China Marine Cast Steel 5K Gate Valve JIS F7363C:

Marine Cast Steel 5K Gate Valve JIS F7363C is a kind of non rising stem gate valve.

Function: open and close the marine pipe system

Suitable Medium: sea water, fresh water, fuel oil and lubrication oil, steam, air..etc.

Advantage: small fluid resistance, easy opening/closing, short structure length, no installment direction requirement, can be used on the pipe system with the two way flow.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7363-1996

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 5K

5. Hydraulic Test Pressure: Body---1.05Mpa, Seat---0.77Mpa

6. Warranty: 12months

7. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Max Working Pressure:

Main Material:

Class B:

1.Body/Bonnet---Cast Steel

2. Seat---Bronze

3. Disc---Bronze

4. Stem---Brass

Class S:

1.Body/Bonnet---Cast Steel

2. Seat---Stainless Steel

3. Disc---Stainless Steel

4. Stem---Stainless Steel

Main Size(mm):
