Marine Cast Steel 10K Screw Down Check Angle Valve JIS F7472
Category:
JIS Marine Valve
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Marine Cast Steel 10K Screw Down Check Angle Valve JIS F7472:
China Marine Cast Steel 10K Screw Down Check Angle Valve JIS F7472:

Marine Cast Steel 10K Screw Down Check Angle Valve JIS F7472 is used to shut off/turn on the medium,adjust the flow rate and prevent the medium flow back in the marine steam, fresh water, water feeding, fuel oil and lubrication oil pipe lines. It is called Marine Cast Steel Angle SDNR Valve, or marine cast steel angle stop check valve.

Technical Specification:

1. Design and manufacturing standard: JIS F7472-1996

2. Inspection and Test standard: JIS F7400

3. Hydraulic Pressure Test: Body---2.1Mpa, Seat---1.54~0.4Mpa

4. Connection Type: Flange

5. Flange Standard: JIS B2220 10K

6. Warranty: 12months

Max Working Pressure:
Fluid Condition Max Working Pressure (Mpa)
Steam of 300℃ 1.0
Steam of 200℃ or less 1.2
Air, oil, gas and pulsation water 1.2
non-shock water of 120℃ or less 1.4
Main Material:

1-Body:Cast Steel

2-Seat: Stainless Steel

3-Disc:Stainless Steel

4-Stem: Stainless Steel

5-Bonnet: Cast Steel

6-Handwheel: Cast Iron

Main Size(mm):

IMPA CODE DN L1 D C No of bolt hole h t H D2 Weight(kgs)
751216 50 120 155 120 4 19 16 240 160 16.3
751217 65 130 175 140 4 19 18 260 200 8
751218 80 140 185 150 8 19 18 265 200 25.3
751219 100 160 210 175 8 19 18 300 250 37
751220 125 180 250 210 8 23 20 350 280 56.6
751221 150 205 280 240 8 23 22 400 315 77.1
751222 200 230 330 290 12 23 22 480 355 116
751223 250 290 400 355 12 25 24 535 400 188
751224 300 320 445 400 16 25 24 610 450 256
