Marine Bronze/Brass Lift Check Valve JIS F7356 5K

Marine Bronze/Brass Lift Check Valve JIS F7356 5K

China Marine Bronze/Brass Lift Check Valve JIS F7356 5K:

Marine Lift Check Valve is a kind of check valve used on the marine pipe system, it is open and close automatically by medium flow and power to prevent the medium backflow,mainly used for medium one-way flow of the line, only allows the medium to flow in one direction.Swing Check Valve shall be installed horizontally in the pipeline. Marine Bronze/Brass Swing Check Valve can be used for sea water, fresh water, fuel oil and lubrication oil pipe system.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7356

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 5K

5.Hydraulic Pressure Test: Body-1.05Mpa, Seat-0.77Mpa~0.4Mpa

6. Max Working Pressure:0.5Mpa for oil and pulsation water, 0.7Mpa for non-shock water of 120℃ or less.

7. Warranty: 12months

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Bonnet:Bronze / Brass

Main Data for Joining(mm):
