China Marine Bronze/Brass Gate Valve JIS F7367 5K:

Marine Bronze/Brass Gate Valve JIS F7367 5K is a kind of rising stem gate valve.

Function: open and close the marine pipe system

Suitable Medium: sea water, fresh water, fuel oil and lubrication oil

Advantage: small fluid resistance, easy opening/closing, short structure length, no installment direction requirement, can be used on the pipe system with the two way flow.

If the nominal size is DN15~DN40, it is the screwed bonnet. If the nominal size is DN50 and above, it is bolted bonnet.

Technical Specification:

1.Design & Manufacturing Standard: JIS F7367

2.Inspection & Test Standard: JIS F7400

3. Connection Type: Flange

4.Flange Standard: JIS B2220 5K

5.Hydraulic Pressure Test: Body-1.05Mpa, Seat-0.77Mpa

6. Max Working Pressure: 0.5Mpa for oil, pulsation water, 0.2Mpa for saturated steam of 205℃ or less, 0.7Mpa for non-shock water of 120℃ or less.

7. Warranty: 12months

8. Certificate: CCS, ABS, BV, DNV/GL, RINA, LR, NK, IRS, RMRS

Main Material:

1-Body: Bronze / Brass

2-Disc: Bronze / Brass

3-Stem: Brass

4-Bonnet:Bronze / Brass

Main Data for Joining(mm):
