Marine Bow Thruster
Category:
Bow Thruster
Certificate:
ABS,LR,BV,DNVGL,NK,KR,IRS,RMRS,CCS
FOB Price:
Get Latest Price Now
Warranty:
12 Months unless specified otherwise
Place of Origin:
China
Request a Quote Print this page
We can supply according to your requirement.
Marine Bow Thruster:
Marine Bow Thruster Description

Marine bow thruster or stern thruster is a transversal propulsion device built into, or mounted to, either the bow or stern, of a ship or boat, to make it more maneuverable. Bow thruster make docking easier, since they allow the captain to turn the vessel to port or starboard side, without using the main propulsion mechanism which requires some forward motion for turning; indeed, the effectiveness of a thruster is curtailed by any forward motion. A stern thruster is of the same principle, fitted at the stern. Large ships might have multiple bow thruster and stern thruster.

Marine Bow Thruster Characteristic

1.Diesel,hydraulic or electric drive.
2.L,Z installation.
3.Input power; 45 KW to 1360 KW.
4.Frequency; 50 Hz,or 60 Hz.

Technical Specification:

Type CTT010 CTT060 CTT110 CTT160 CTT170
Input speed 1470 1170 1470 1170 1470 1170 1470 1170 1470 1170
Frequency(Hz) 50 60 50 60 50 60 50 60 50 60
Input power .(KW/h.p.) 63/86 50/68 125/170 100/136 200/272 200/272 280/380 280/380 420/570 336/457
Max.Thrust(KN) 9.5 7.9 17.5 14.5 28 28 42 42 63 51
Length of the simplified.(mm) 1000 1000 1000 1500 1500
Thickness of tunnel(mm) 12 12 15 20 20
Propeller Diameter(mm) 500 630 800 1000/1100 1300
Weight(kg) 300 430 730 1450 1510

Type CT300T CTT550 CTT1010
Input speed 1770 1470 1470 1170 1170 970
Frequency(Hz) 60 50 50 60 60 50
Input power .(KW/h.p.) 550/748 550/748 900/1224 725/986 1250/1700 1000/1360
Max.Thrust(KN) 72 72 125 110 183 155
Length of the simplified.(mm) 1500 2000 2500
Thickness of tunnel(mm) 20 20 20
Propeller Diameter(mm) 1500 1750 2100
Weight(kg) 2450 2680 3200

Installation Type:
