Integral Sliding Door For Wheelhouse
Integral Sliding Door For Wheelhouse:
| TYPE |
SIZE OF DOORWAY L B |
SIZE OF FRAME L1 B1 |
SIZE OF OPENING L2 B2 |
SIZE OF DOOR L3 B3 |
D |
|
A B C |
1700 700 | 1760 810 | 1765 815 | 2250 1860 | T+60 |
| 1700 900 | 1760 960 | 1765 965 | 2250 2160 | ||
| 1800 900 | 1760 960 | 1865 965 | 2350 2160 | ||
| 1800 1000 | 1860 1060 | 1865 1065 | 2350 2360 |
| WEIGHT KG | ||
| A | B | C |
| 56 | 42 | 40 |
| 62 | 48 | 46 |
| 66 | 52 | 50 |
| 72 | 58 | 56 |
