CV-90/30 Marine air compressor
Models: CV-90/30 Marine air compressor
Type: V type, two columns, water-cooled, medium pressure piston, elastic coupling straight league transmission
Displacement: 90.0 m3 / h
The rated pressure: 3.0 MPa
Product features
1.With highly efficient, low noise, low exhaust temperature, stable running, etc.
2.Apply to ship host and a variety of large diesel engine start, can also be used for hydropower station of braking, blow molding and rubber products.
3.All kinds of valves, instruments, containers, pressure testing and other needs 1.5 ~ 3.0 MPa gas source of various industrial sectors.
4.According to the needs of users of products can provide the following functions: two main for the functions of each control, temperature control, inlet pressure controller, exhaust outlet high pressure hose.
Main Technical Parameter
| Model | Displacement | Specified | Rotating | Motor Power | Dimension （L×W×H） | Weight | ||
| Pressure | Speed | |||||||
| m3/h | m3/ min | MPa | r/min | kW | HP | mm | kg | |
| CZ-20/30SZK | 20 | 0.34 | 3.0 | 960 | 5.5 | 7.5 | 900×600×850 | 250 |
| CZ-20/30SZK | 1000 | 1070×490×810 | 225 | |||||
| CV-30/30 | 30 | 0.5 | 720 | 7.5 | 10 | 1230×730×690 | 330 | |
| CV-40/30 | 40 | 0.67 | 870 | 11 | 15 | 1230×730×690 | 340 | |
| CV-50/30 | 50 | 0.83 | 970 | 11 | 15 | 1230×730×690 | 340 | |
| CV-90/30 | 90 | 1.5 | 730 | 22 | 30 | 1600×1010×1050 | 900 | |
| CV-120/30 | 120 | 2 | 975 | 30 | 40 | 1600×1010×1050 | 1000 | |
