MARINE EQUIPMENT & SPARE PARTS

CQX(W) Series Submersible Pump

Reliable marine equipment supplied with technical support, quality control and worldwide delivery.

Loading product images...

CQX(W) Series Submersible Pump

Category: Marine Submersible pump

Certificate: ABS, LR, BV, DNVGL, NK, KR, IRS, RMRS, CCS

FOB Price: Get Latest Price Now

Warranty: 12 Months unless specified otherwise

Place of Origin: China

Request a Quote Download Datasheet

We can supply according to your requirement.

CQX(W) Series Submersible Pump

The pump is basically applicable to marine emergency survival system and removal of accumulated water in the cabin. It is widely used to let sludge, liquid waste, city life sludge, which with some solid and fiber in town planning, pumping station, and architecture and so on. Similarly, it is used to fire damper, irrigation in country.

Technical parameter:

Tpye	Capacity	Head	efficiency	power	rpm	Throughout max.
	Q (m3/h)	H (m)	%	P (kw)	N (r/min)	mm
CQX(W)10-10-1	10	10	44	1	2900	25
CQX(W)15-7-1	15	7	47	1		25
CQX(W)10-15-15	10	15	44	1.5		25
CQX(W)15-10-10	15	10	47	1.5		25
CQX(W)25-8-1.5	25	8	51	1.5		25
CQX(W)15-20-2.2	15	20	47	2.2		40
CQX(W)25-14-2.2	25	14	50	2.2		40
CQX(W)40-10-2.2	40	10	54	2.2		40
CQX(W)20-22-3	20	22	49	3		40
CQX(W)30-16-3	30	16	52	3		40
CQX(W)40-12-3	40	12	54	3		40
CQX(W)20-25-4	20	25	49	4		40
CQX(W)30-18-4	30	18	52	4		40
CQX(W)40-15-4	40	15	54	4		40
CQX(W)60-13-4	60	13	57	4		40
CQX(W)25-30-5.5	25	30	52	5.5	1470	25
CQX(W)30-21-5.5	30	21	52	5.5		50
CQX(W)45-18-5.5	45	18	55	5.5		50
CQX(W)65-15-5.5	65	15	45	5.5		50
CQX(W)70-14-5.5	70	14	58	5.5		50
CQX(W)100-8-5.5	100	8	60	5.5		50
CQX(W)20-40-7.5	20	40	51	7.5	2900	40
CQX(W)45-30-7.5	45	30	52	7.5	1470	45
CQX(W)50-27-7.5	50	27	55	7.5		45
CQX(W)70-20-7.5	70	20	58	7.5		45
CQX(W)100-13-7.5	100	13	60	7.5		50
CQX(W)150-8-7.5	150	8	62	7.5		50
CQX(W)45-32-11	45	32	55	11		50
CQX(W)70-22-11	70	22	58	11		50
CQX(W)100-16-11	100	16	59	11		50
CQX(W)150-10-11	150	10	61	11		50
CQX(W)70-32-15	70	32	58	15		50
CQX(W)100-22-15	100	22	59	15		50
CQX(W)250-13-15	250	13	65	15		50
CQX(W)150-17-15	150	17	62	15		50
CQX(W)150-20-45	150	20	65	15	970	50
